ZYB gear pump slag
- Brand: ???Park TaiBang
- Type: ???ZYB－125
ZYB slag gear pump is mainly for the characteristics of China's oil industry and design, its heavy oil , coal tar , diesel and other impurities containing low-grade low-grade burning oil has better adaptability . ZYB gear pumps , ZYB gear pumps are widely used in petroleum , chemical industry , building materials, household chemicals , especially road construction equipment , asphalt mixing plant , road fuel injection, pouring , and other machinery, equipment and other types of ancillary burner oil and direct injection occasion.
Tips: Due to the quality of all types of burning oil , containing impurities and whether there is much resistance, viscosity size , temperature, level , and many are quite different , so the slag ZYB gear pump working life will vary according to their own usage, configuration backup pump discretion , so as not to affect your use .
The pump according to structural characteristics , materials, and use the occasion divided into the following five series
ZYB gear pumps , ZYB gear pump (1.5MPa or less )
The main parts of slag trisomy ZYB gear pump ( pump , front cover , back cover ) using ordinary cast iron HT200 , gears, shafts , thrust plate made of alloy steel and heat treatment have a higher hardness and wear resistance. Mainly used below 200 ℃ and low jet fuel delivery occasions
ZYB slag gear pump (1.5MPa) Performance Parameters
| 型 號 |
口徑 |
流量 |
工作壓力MPa |
吸入壓力MPa |
轉(zhuǎn)速 |
電機(jī) |
||
|
m3/h |
L/min |
功率 |
型號 |
|||||
|
ZYB－18.3 |
G3/4" |
1.1 |
18.3 |
1.45 |
-0.05 |
1500 |
1.5 |
Y90L－4 |
|
ZYB－33.3 |
2.0 |
33.3 |
1500 |
2.2 |
Y100L1-4 |
|||
|
ZYB－55 |
G1″ |
3.3 |
55 |
0.33 |
1500 |
1.5 |
Y90L－4 |
|
|
ZYB－83.3 |
G1?" |
5.0 |
83.3 |
1500 |
2.2 |
Y100L1-4 |
||
|
ZYB－125 |
Φ50 |
7.5 |
125 |
0.60 |
1000 |
4.0 |
Y132M1-6 |
|
|
ZYB－167 |
10 |
167 |
0.60 |
1000 |
4.0 |
Y132M1-6 |
||
|
ZYB－200 |
12 |
200 |
0.33 |
1500 |
4.0 |
Y112M－4 |
||
|
ZYB－250 |
15 |
250 |
0.60 |
1500 |
7.5 |
Y132M－4 |
||
|
ZYB－300 |
Φ70 |
18 |
300 |
0.36 |
1000 |
5.5 |
Y132M2-6 |
|
|
ZYB－483.3 |
29 |
483.3 |
1500 |
7.5 |
Y132M－4 |
|||
|
ZYB－633 |
Φ100 |
38 |
633 |
0.28 |
1000 |
11 |
Y160L－6 |
|
|
ZYB－960 |
58 |
960 |
1500 |
18.5 |
Y180M－4 |
|||
